Boat Specifications
Identification:
Family Name Pro Guide™
Generic Type (Primary) Fishing
Manufacturer Country USA
Revision Status Carryover
Competitor Code BOA20FBA0000
IsEmbargoed No
IsWIP No
IsPrelim No
IsCurrent Yes
Parent Company Tracker Marine Group
Technical Specifications
Length (in/mm/ft/m) 198 / 5000 / 16.5 / 5
Length (ft/ft) 16
Length (ft/in) 6
Beam (in/m) 88 / 2.2
Deadrise (deg) 20
Transom Height (mm/in) 508 / 20
Number Of Pontoons 0
Dry Weight (lbs/kg) 1194 / 541.6
Fuel Capacity (gal/l) 25.5 / 96.5
Number of Passengers 5
Weight Capacity (lbs/kg) 1200 / 544.3
Min Recommended Horsepower (bhp/kW) 60 / 44.8
Max Recommended Horsepower (bhp/kW) 90 / 67.2
Number Of Fresh Water Holding Tanks 0
Total Fresh Water Tank Capacity (gal/l) 0 / 0
Total Gray Water Tank Capacity (gal/l) 0 / 0
Total Black Water Tank Capacity (gal/l) 0 / 0
Number Of Water Ballast Tanks 0
Total Water Ballast Tank Capacity (gal/l) 0 / 0
Engine
Engine Brand Name Fourstroke
Engine Type In-line
Cylinders 4
Engine Stroke 4-Stroke
Horsepower (bhp/kW) 60 / 45
Cooling Water (Open Loop)
Valves 8
Valves Per Cylinder 2
Valve Configuration SOHC
Bore (mm/in) 65 / 2.56
Stroke (mm/in) 75 / 2.95
Displacement (l) 1
Starter Electric
Fuel Requirements Regular
Fuel Type Gas
Turbocharged No
Supercharged No
Engine Model Code 60ELPT
Engine Manufacturer Mercury
Engine Trim 60HP ELPT
Full Throttle RPM Range Low 5500
Full Throttle RPM Range High 6000
Engine Dry Weight (lbs/Kg) 247 / 112
Salt Water Capable Yes
Engine Alert System Type Visual / Audible
Emergency RPM Reduction Yes
Number Of Engines 1
Engine Configuration Outboard
Fuel Injector Yes
Carburetor No
Carburetion Type Fuel Injected
Instrumentation
Tachometer Standard
Speedometer Standard
Fuel Level Warning Type Gauge
Trim Indicator Standard
Fish Finder Standard
Drive Line
Propulsion Type Propeller
Gear Ratio (s) 1.83:1
Trim System Type Power
Twin Propeller No
Counter Rotating Capable No
Steering
Outboard Steering Control Remote
Auto Pilot No
Exterior
Hull Material Aluminum
Hot Water No
Convenience
Anchor Standard
Bilge System Type Electric Pump
Topside / Cabin
Helm Seating Configuration Chair
Number Of Helm Seats 1
Helm Roof Type Open Top
Pilot House Door No
Cockpit Flooring Type Vinyl
Cockpit Table No
Number Of Cockpit Chairs 2
Number Of Cockpit Sofas 0
Number Of Open Bow Seats 0
Number Of Sofas 0
Number Of Chairs 0
Number Of Convertible Beds 0
Number Of Full Beds 0
Number Of Single Beds 0
Total Sleeping Capacity 0
Number of Queen Beds 0
Galley Table Configuration No Galley Table
Convection No
Number Of Bridge Seats 0
Bridge Carpeting No
Bridge Table No
Number Of Bridge Chairs 0
Number Of Bridge Sofas 0
Full Head No
Fishing
Fishing Rod Holders Standard
Number of Fishing Pedestal Chairs 3
Total Fishbox Capacity (gal/l) 23 / 97.5
Fishbox Pump Yes
Trolling Motor Brand Minn Kota®
Air Conditioning & Heater
Cockpit Heater No
Cabin Heater No
Bridge Heater No
Towing & Hauling
Trailer Standard
Glass
Walk-Through Windshield Yes
Audio & Communication
Satellite
Hummingbird - Fishing tracker
Bimini Top & Boat Cover!
